Heatproof MAZ Parts Shaft Clutch Coupling Assy For MAZ236HE Engine Parts 183 - 1601180 - 01

China Heatproof MAZ Parts Shaft Clutch Coupling Assy For MAZ236HE Engine Parts 183 - 1601180 - 01 supplier
Heatproof MAZ Parts Shaft Clutch Coupling Assy For MAZ236HE Engine Parts 183 - 1601180 - 01 supplier Heatproof MAZ Parts Shaft Clutch Coupling Assy For MAZ236HE Engine Parts 183 - 1601180 - 01 supplier Heatproof MAZ Parts Shaft Clutch Coupling Assy For MAZ236HE Engine Parts 183 - 1601180 - 01 supplier

Large Image :  Heatproof MAZ Parts Shaft Clutch Coupling Assy For MAZ236HE Engine Parts 183 - 1601180 - 01

Product Details:

Place of Origin: China
Brand Name: Generic
Model Number: 182.1601180-01

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: negotiation
Packaging Details: standard export box,package size 33x23x18cm for 2 piece
Delivery Time: 1-3days if goods in stock
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000pcs per month
Contact Now
Detailed Product Description
Product Name: Clutch Release Coupling Assy,Clutch Release Brg Application: Truck
Part Number: 183 - 1601180 - 01 Gross Weight: 5.5kg
Performance: Heatproof And Wearproof Material: Iron

Clutch Release Coupling Assy 183 - 1601180 - 01 For MAZ236HE Engine Parts





Quick Detail:



Item Type: Clutch Release Coupling Assy

Engine Model: MAZ 236HE

Part Number: 183 - 1601180 - 01

Application:Truck

Engine Type: Diesel

Condition: New

Sample:Available





Specifications:



Clutch Release Coupling Assy 183 - 1601180 - 01 For MAZ236HE Engine Parts

Product name Clutch Release Coupling Assy
Model MAZ 236HE
Part No 183 - 1601180 - 01
Suitable for Truck
Sample order Available
Net weight 5.5kg
Package Neutral package or special package to meet your requirements
Payment T/T, L/C, Westernunion, MoneyGram





Description:



Clutch Release Coupling Assy ​ of 236HE engines for MAZ trucks

182.1601183 Safety ring
182.1601198-10 Ring
182.1601199-01 Lock ring
183.1601197 Locking ring
183.1601195 Deflecting washer
46 1214 0538 Bearing 70-117
182.1601193-02 Bearing bushing
183.1601185-01 Clutch release coupling
236-1601230-À Bearing lubrication hose, assy
182.1601188 Coupling spring
182.1601190 Spring clamp



Parameter of MAZ Engine Model 236HE



Number of cylinders 6
Cylinder bore, mm 130
Piston stroke, mm 140
Engine displacement, L 11,15
Compressor ratio 16,5
Rated power, kW (hp) 220,6 (300)
Maximum torque, N.m (kgf.m) 1274 (130)
Crankshaft speed at maximum -1 torque, min , max 1100-1300
Fuel-air mixing method Direct injection
Fuel feed equipment Separate type
High-pressure fuel injection pump Six-plunger (in-line or V-type)
Injectors Closed, with multi-jet sprayers
Lubrication system Composed type: pressure-forced and splashing, with oil cooling in oil-liquid heat-exchanger. Besides, oil delivers through the system of channels and pipelines for jet cooling pistons



Heatproof MAZ Parts Shaft Clutch Coupling Assy For MAZ236HE Engine Parts 183 - 1601180 - 01

Heatproof MAZ Parts Shaft Clutch Coupling Assy For MAZ236HE Engine Parts 183 - 1601180 - 01





Packaging & Delivery



Delivery time: 1-3days(if goods in stock only 1 day,if out of stock more than 7days)

Packaging Detail:Standard or as per your requirement

Port:Huangpu,Guangzhou





More about our service:



1. Packing:Standard or as per customer requirement

2. Market:popular in Southeast Asia,Mid-East,South America,Africa and so on.

3. Delivery time:For stock parts 2-3days,for out of stock parts 15-30days

4. Shipment:Vessel,Air freight or Express(DHL,TNT,FedEx,UPS,EMS)

5. Your logo and design are welcome

6. Able to manufacture according to customer’s quality

7. Best control of product quality

8. Fast delivery,excellent after-sale service

9. Over 10 years experience.
