6136-21-2210 Cylinder Sleeve Engine Cylinder Liner For Komatsu 6D105

China 6136-21-2210 Cylinder Sleeve Engine Cylinder Liner For Komatsu 6D105 supplier
6136-21-2210 Cylinder Sleeve Engine Cylinder Liner For Komatsu 6D105 supplier 6136-21-2210 Cylinder Sleeve Engine Cylinder Liner For Komatsu 6D105 supplier

Large Image :  6136-21-2210 Cylinder Sleeve Engine Cylinder Liner For Komatsu 6D105

Product Details:

Place of Origin: China
Brand Name: Generic
Model Number: 6136-21-2210 6D105

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: negotiation
Packaging Details: standard export box,package size 45x30x30cm for 6 piece
Delivery Time: 1-3days if goods in stock
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000pcs per month
Contact Now
Detailed Product Description
Product Name: Engine Cylinder Liner Cylinder Sleeve Application: 6D105
Part Number: 6136-21-2210 Material: Iron
Diameter: 105mm Cylinder Number: 6





 6136-21-2210 Cylinder Sleeve Engine Cylinder Liner For Komatsu 6D105





Specifications:



Item Type: Cylinder Liner Cylinder Sleeve

Engine Model: 6D105

Part Number: 6136-21-2210

Engine Type: Diesel

Condition: New

Sample:Available

International standard





Description:



6136-21-2210 Cylinder Sleeve Engine Cylinder Liner For Komatsu 6D105

Product name Cylinder Liner Cylinder Sleeve
Model 6D105
Part No 6136-21-2210
Inside Diameter 105mm
Length 223mm
Outside Diameter 119mm
OD of shoulder 127mm
Height of top end 10.1mm
Net weight 6.0kg
Package Neutral package or special package to meet your requirements
Payment T/T, L/C, Westernunion, MoneyGram



6136-21-2210 Cylinder Sleeve Engine Cylinder Liner For Komatsu 6D105





Other Komatsu Cylinder Sleeve Part Number We Have:



Engine Model Part Number Inside Diameter Outside Diameter Length OD of shoulder Height of top en
4D92 6140-21-2211 92 106 185 115 10
4D94 6144-21-2211 94 108 181 117 10
4D95  6D95 6207-21-2121 95 98 180 104 4
4D95 6D95 6110-21-2121 94.2 98 180
4D120 6110-21-2212 120 140 293 150 13
4D130 6115-21-2211 130 146 293 156 13
6D102 6736-29-2110 101.5 104.5 200
4D105 6130-22-2213 105 118 228 125 10
4D105 6130-22-2310 105 118 223 125 10
6D105 6136-23-2210 105 119 223 127 10.1
6D107 6754-21-2211 106.5 109.56 200
6D108 6222-21-2210 108 112 219.5 120 5
6D110 6138-21-2210 110 115 225 120 5
6D114 6742-01-5159 114   235.5
6D125 6150-21-2221 125 142 256.3 153 10.2
6D140 6211-21-2210 140 158 283 170.5 11
6D155 6128-21-2216 155 176 327 186 14
6D170 6162-23-2210 170 190 342 206 14





Popular Engine Liner/Sleeve Mocun Have:



model liner part No.

4BA1 5-12111-055-1/8-97176-626-0
4BB1 5-11261-242-0/1-12111-745-0 9-11261-205-0
6BB1 5-11261-242-0/9-11261-118-0 5-11261-001-0
4BC1 5-11261-014-0/5-11261-014-2
4BC2 5-11261-014-0/5-11261-014-2
4BD1 5-11261-004-0/9-11262-118-0 9-11261-205-0
4BD1 1-11261-242-0 9-11261-205-0
6BD1 5-12161-004-0/9-12161-118-0 5-11261-001-0
6BD1 1-11261-242-0/9-11261-118-0 5-11261-001-0
4BD1(NEW) 5-11261-242-0/9-11261-118-0 9-11261-205-0
4BD1T 5-11261-004-0/9-11261-118-0 9-11261-205-0
4BD1T 5-11261-004-0/9-11261-118-0 9-11261-205-0
6BD1T 5-11261-242-0/9-11261-118-0
4BD2T(1992'-1994') 5-11261-004-0/9-11261-118-0/1-11261-242-0
4BD2T(NEW 1995'-1998') 5-11261-004-0/9-11261-118-0/1-11261-242-0
4BE1 5-11261-016-2
4BE1(TYPE 2) 5-11261-016-2
6BF1 1-11261-119-0 1-11261-088-0/5-11261-010-0/1-11261-147-2
6BG1 1-11261-250-0/1-11261-119-0 1-11261-088-0/5-11261-010-0/1-11261-147-2
6BG1T 1-11261-119-0 1-11261-088-0/5-11261-010-0/1-11261-147-2
6BG1T 1-11261-119-0/1-11261-250-0
6BG1TC 1-11261-119-0/1-11261-250-0
4EC1 8-94286-828-0
4EC1T /
4EE1T /
4EE1T(NEW) /
4EE1 /
4FB1 5-11261-119-0 8-94389-119-0
4FC1 5-11261-119-0 8-94389-887-1
4FD1 8-94286-454-0
4FG1 8-94286-873-0
4HE1T 8-97176-723-0/8-97176-724-0/8-97176-725-0/8-97176-726-0/8-97176-728-0
4HE1TC 8-94391-600-0
6HE1 8-94396-332-0
6HE1T 8-94391-600-0/8-94391-601-0 8-49390-530-0
6HE1-T 8-94391-600-0/8-94391-601-0
4HF1 8-94389-276-3 8-97176-727-0/8-97144-174-0
4HF1 8-971716-727-0 8-97176-727-0/8-97144-174-0
4HF1 8-97144-174-0/8-97176-727-0
4HF1(NEW) 8-97144-174-0/8-97176-727-0
4HG1 8-97351-558-0/8-97144-178-0
4HG1/4HG1T 8-97351-558-0/8-97144-178-0
6HH1 8-94393-273-1/8-94396-847-0
6HH1/6HH1T 8-94391-273-1 8-94396-847-0
4JA1 8-97176-693-0/8-94462-130-0 8-94110-144-0
4JA1(NEW) 8-97176-693-0/8-94462-130-0 8-94110-144-0
4JB1 8-97176-685-0/8-94247-861-2 8-94247-861-0(2)
4JB1(NEW) 8-97176-685-0/8-94247-861-2 8-94247-861-0(2)
4JB1T 8-97176-685-0/8-94247-861-2
4JC1 5-11261-015-0/5-11261-015-2/8-94169-883-1 9-11261-118-0 8-94456-791-0
4JG2 8-97176-701-0/8-94456-791-0
4JG2T 8-97176-701-0/8-94456-791-0
4JH1-TC 8-97176-702-0
