R250 Brushless Alternator Voltage Regulator AVR , 1 Phase Automatic Voltage Controller 2 Wires

China R250 Brushless Alternator Voltage Regulator AVR , 1 Phase Automatic Voltage Controller 2 Wires supplier
R250 Brushless Alternator Voltage Regulator AVR , 1 Phase Automatic Voltage Controller 2 Wires supplier R250 Brushless Alternator Voltage Regulator AVR , 1 Phase Automatic Voltage Controller 2 Wires supplier

Large Image :  R250 Brushless Alternator Voltage Regulator AVR , 1 Phase Automatic Voltage Controller 2 Wires

Product Details:

Place of Origin: China
Brand Name: Generic
Model Number: R250

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: negotiation
Packaging Details: standard export box
Delivery Time: 1-3days if goods in stock
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000pcs per month
Contact Now
Detailed Product Description
Product Name: Automatic Voltage Regulator Model: R250
Weight: 0.35kg Generator Type: Brushless Type
Size: 11.5*5*4.7cm



R250 Brushless Alternator Automatic Voltage Regulator AVR Voltage Regulator




Specifications:


R250 Brushless Alternator Automatic Voltage Regulator AVR Voltage Regulator
1. Type: Automatic Voltage Regulator
2. Condition:New
3. This type is in stock now.




Description:



R250 is a half-wave phase controlled thyristor type Auto Voltage Regulator and forms part of the excitation system for a brushless generator.

In addition to regulating the generator voltage, the AVR circuitry includes under speed and sensing loss protection to ensure safe, reliable control of the generator.

Positive voltage build up from residual levels is ensured by the use of proficient semiconductors in the power circuitry of the AVR. Which is linked with the main stator windings and the exciter field windings to offer closed loop control of the output voltage with load regulations of +/- 1.5%



Sensing/Power input:

Voltage:120 (90-140VAC)

1 phase,2 wires, with copper jumper options



Magnetic Field Output:

Voltage:Max 100VDC at 207VAC input

Current:Continuous 8A Intermittent 10A within 10 seconds



Pressure Regulating Accuracy:

<±1% RMS with 4% engine governing





Our Company Mocun Machinery Parts that strive to provide high quality excavator,bulldozer,loder,truck engine products and hydraulic products.

We supply Genuine & Replacement parts as following:



1. Diesel engine piston, piston pin ,piston rings, piston pin clip, liner etc.



2. Connecting rod, connecting rod bush, connecting rod bearing shells etc



3. Crankshaft, crankshaft oil seal,crankshaft bearing shell, piston cooling nozzle etc



4. Camshaft, camshaft thrust pad, tappet, push rod, camshaft gear etc.



5. Cylinder head, rocker arm, valve sets, valve springs, valve seat, collar,oil seal etc.



6. Turbocharger, Filters, inter-cooler etc.



7. Pumps(fuel transfer pump, lube oil pump, water pump), lube oil cooler core etc.



8. Fuel oil injector, injector nozzle, connector, common rail, high pressure pump etc



9.  Starter, electronic parts, governor, air compressor, alternator, fan, belt etc.



10. Gaskets, o-rings, fuel pipes, intake & exhaust pipes, sensors etc



11. Other relevant parts





More Excavator Engine Spare Parts We have:

6BD5.9,6CT8.3,4BT,6BTAA,NH220,NT855,LTA10,KTA19,KTA38,etc

3066,3064,3306,3304,3204,3208,3116,3406,3408,3412,D330A,
D330C,D343,D348,D399,D353,C9,C10,3508,3516,3114,etc

2D92,4D92,4D94,3D95,4D95L,S495,6D95,S6D95,S6D105,6D105,S6D115,S6D102,4D130,4D120,4D105-1,4D105-5,4D106,SD107,S6D108,S6D110,S6D125,S6D140,S6D155,S6D170

S6KT,S4KT,S4F,S4E,S4S,S6A,S6A2,S6B,S6B3,S12R,S6N,S6R,S4KT,K4N,K4M

6D34T,6D31T,4D34T,4D31T,4M4O,4M50 , 6M60, 6D14T,6D15T,6D16T,6D110,6D22,6D24T,6BD1,6DS7,8DC8,8DC9,8DC11,6D20,6D24

3TNV84,3TNE82,4TNV84,4TNE84,4TNE88,3TNV75,3TNV74,3TNV78,4TNE94,4TNE94,4TNV94L,4TNV106, 4TNV98

3KC1,3KR2,4JB1,4JC1,4BD1T,C240,6BD1T,6BG1T,D500,6WQ1,6SD1T,6RB1T,6HK1T,6BB1,6BF1,DA640,DA220,E120,4LE1,4LE2

D1146,D2366,DB58,DO846,DB33

EC140B,EC210B,EC240B,EC290B,EC360B
HINO:
HO6CT,HO7CT,EP100,EM100,EL100,EB100,WO6E,DS50,DS70,EH700,DK10,EF750,F20C,J08C,J05E,J08E,W06D




Our Packaging & Delivery


Shipping:

Weight Transport Means Transport Time Comments
<50kg UPS/DHL/FEDEX,door to door service 3-7 days Fast,convenient
50-150kg by air 3-10 days Fast,economic,consignee has to do customs clearance
150>kg by sea 10-50 days Slow,economic,it takes some time for customs and clearance


Packing:
1. individual package.
2. Iner and Outer Package
3. Bulk order with pallet
4. Customized package



Perfect Service:


1. Your inquiry will answer within 24 hours.
2. You can get our best price.
3. When you confirmed frice,we send the commercial invoice
4. You confirmed the invoice and arrange the bank transfer,we will pack the goods well and ship the goods asap.
5. You can get the reliable after-sales service,when the commodities arrived to your side.



Our Advantage:


1. High-quality Replacement Parts
2. Large Stock Available Within fast delivery
3. Variable Payment:L/C, T/T, Paypal, Western Union,Trade Assurance
4. Reliable After-sales Service



Company Information:


Q: Are you trading company or manufacturer ?
A: We are trading company, foucs on offering solution for customer.
Q: How long is your delivery time?
A: Generally it is 1-2 days if the goods are in stock. or it is 3-30 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for quality testing but not free.
Q: Why choose MocunParts?
A: Professonal in Excavator Parts for years in guangzhou market, With large stock, fast delivery, competitive price and guaranteed servcie.







.
