Folding Komatsu Air Suspension Seats , Digger Custom Seats For Heavy Duty Equipment Parts

China Folding Komatsu Air Suspension Seats , Digger Custom Seats For Heavy Duty Equipment Parts supplier
Folding Komatsu Air Suspension Seats , Digger Custom Seats For Heavy Duty Equipment Parts supplier Folding Komatsu Air Suspension Seats , Digger Custom Seats For Heavy Duty Equipment Parts supplier

Large Image :  Folding Komatsu Air Suspension Seats , Digger Custom Seats For Heavy Duty Equipment Parts

Product Details:

Place of Origin: China
Brand Name: Generic

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: Negotiable
Packaging Details: Standard or as per your requirement
Delivery Time: 3-7workdays
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000pcs/month
Contact Now
Detailed Product Description
Product Name: Suspension Folding Seat Excavator Seats Fit For: Heavy Duty Equipment
Condition: New Backrest Angle: 45°-178°
Net Weight: 32kg Volume: 0.28m³
Mounting Dimension: 215*295mm


Komatsu Suspension Folding Seat Excavator Seats For Heavy Duty Part


Specification:

Part Name:Suspension Folding Seat Excavator Seats
Suitable for:Excavator,Bulldozer,Forklift and other construction equipment.
MOQ:20PCS
Delivery tiem:With 10 days
Shipping:By sea
Mounting Dimension:215*295mm
Fabric Material:Blue flower knitted fabric
Filler:Polyurethane high resilience sponge
Back and front strok:170mm
Damping Strok:60mm
Seat Configuration:Mechanical damping base/Slide double lock/Three layers of dust cover


Description:



Product nameKomatsu Suspension Folding Seat Excavator Seats For Heavy Duty Part
ConditionNew
QualityExcellent
Suitable forExcavator
Sample orderAvailable
PackageNeutral package or special package to meet your requirements
PaymentT/T, LC, Western union, MoneyGram


Instructions:
1. Handrail can be locked
2. The adjuster handle can adjust the backrest angle forward and backward.
3. Beautiful dust cover
4. The weight can be flexibly adjusted according to the driver's weight.
5. A buttons can adjust the front and back of the seat.

Seat Function Parameters:
Head restraint:Up and down three stalls lock adjustment,travel adjustment 85mm
Seat Fabric(optional):Blue/Black/Flower Knitted fabrics,PU artificial leather,leather
Seat skeleton:20mm*20mm*2.0mm tube
Seat Sponge:High resilience sponge
Backrest angle adjustment range:45-179degree
The backrest can be at an angle of 45 degrees to the cushion
Backrest back with the cushion was 179 degrees angle

Handrail Parameters:
Angle adjustment:Turn the yellow knob at anytime to adjust the armrest position,up with
the backrest parallel,down with the back was 145 degrees angle.

Shock absorber parameters:
The driver to sit up automatically inflated.
Automatically reduce the exhaust after the driver left.
Working pressure:0.8~1.2Mpa.
Suspended air bag cushioning.

Dust Cover Device:
The upper end is fixed on the dust cover bracket at the bottom of the seat and
the lower end is fixed on the dust cover bracket at the bottom of the shock absorber


Product Picture:

Folding Komatsu Air Suspension Seats , Digger Custom Seats For Heavy Duty Equipment Parts
Folding Komatsu Air Suspension Seats , Digger Custom Seats For Heavy Duty Equipment Parts


More Excavator Engine Spare Parts We have:
6BD5.9,6CT8.3,4BT,6BTAA,NH220,NT855,LTA10,KTA19,KTA38,etc
3066,3064,3306,3304,3204,3208,3116,3406,3408,3412,D330A,
D330C,D343,D348,D399,D353,C9,C10,3508,3516,3114,etc
2D92,4D92,4D94,3D95,4D95L,S495,6D95,S6D95,S6D105,6D105,S6D115,S6D102,4D130,4D120,4D105-1,4D105-5,4D106,SD107,S6D108,S6D110,S6D125,S6D140,S6D155,S6D170
S6KT,S4KT,S4F,S4E,S4S,S6A,S6A2,S6B,S6B3,S12R,S6N,S6R,S4KT,K4N,K4M
6D34T,6D31T,4D34T,4D31T,4M4O,4M50 , 6M60, 6D14T,6D15T,6D16T,6D110,6D22,6D24T,6BD1,6DS7,8DC8,8DC9,8DC11,6D20,6D24
3TNV84,3TNE82,4TNV84,4TNE84,4TNE88,3TNV75,3TNV74,3TNV78,4TNE94,4TNE94,4TNV94L,4TNV106, 4TNV98
3KC1,3KR2,4JB1,4JC1,4BD1T,C240,6BD1T,6BG1T,D500,6WQ1,6SD1T,6RB1T,6HK1T,6BB1,6BF1,DA640,DA220,E120,4LE1,4LE2
D1146,D2366,DB58,DO846,DB33
EC140B,EC210B,EC240B,EC290B,EC360B
HINO:
HO6CT,HO7CT,EP100,EM100,EL100,EB100,WO6E,DS50,DS70,EH700,DK10,EF750,F20C,J08C,J05E,J08E,W06D
