High Precision YaMZ Direct Drive Fan For Excavator Engine Maz Auto Parts 236HE-1308011-E

High Precision YaMZ Direct Drive Fan For Excavator Engine Maz Auto Parts 236HE-1308011-E
High Precision YaMZ Direct Drive Fan For Excavator Engine Maz Auto Parts 236HE-1308011-E High Precision YaMZ Direct Drive Fan For Excavator Engine Maz Auto Parts 236HE-1308011-E High Precision YaMZ Direct Drive Fan For Excavator Engine Maz Auto Parts 236HE-1308011-E

Large Image :  High Precision YaMZ Direct Drive Fan For Excavator Engine Maz Auto Parts 236HE-1308011-E

Product Details:
Place of Origin: China
Brand Name: Generic
Model Number: 236HE-1308011-E
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: negotiation
Packaging Details: standard export box,package size 60x52x22cm for 4 pieces
Delivery Time: 1-3days if goods in stock
Payment Terms: T/T, Western Union, MoneyGram

High Precision YaMZ Direct Drive Fan For Excavator Engine Maz Auto Parts 236HE-1308011-E

Description
Product Name: Fan Drive Assy Appliion: Truck
Part Number: 236HE-1308011-E Gross Weight: 9.5kg
Performance: Heatproof And Wearproof Material: Cast Iron
High Light:

maz auto parts

,

truck engine spare parts

YaMZ Fan Drive Assy For Excavator Engine Model 2363HE OEM 236HE-1308011-E



Quick Detail:

Item Type:Fan drive assy

Engine Model: MAZ 236HE

Part Number:236HE-1308011-E

Appliion:Truck

Engine Type: Diesel

Condition: New

Sample:Available





Specifiions:

MAZ Flywheel For Excavator Engine Model 2363HE2 Part Number 236-1005115-K

Product name Fan Drive Assy
Model MAZ236HE
Part No 236HE-1308011-E
Suitable for Heavy Duty Equipment
Sample order Available
Net weight 9.0kg
Package Neutral package or special package to meet your requirements
Payment T/T, L/C, Westernunion, MoneyGram





Description:



236HE FAN DRIVE of engines for MAZ trucks

236HE-1308011-E Fan drive,assy
238Í-1308012 Fan impeller,assy
236-1308090-B2 Elastic coupling, assy
236-1308025-B2 Fan drive pulley
45 9824 6266 Key
236HE-1308102 Housing
236-1308108-B Gasket
236HE-1308512 Distance bushing, assy
236-1308107-À Thrust flange
210-1701230 Collar, assy
236HE-1308050-B Shaft



Parameter of YaMZ Engine Model 236HE

Number of cylinders 6
Cylinder bore, mm 130
Piston stroke, mm 140
Engine displacement, L 11,15
Compressor ratio 16,5
Rated power, kW (hp) 220,6 (300)
Maximum torque, N.m (kgf.m) 1274 (130)
Crankshaft speed at maximum -1 torque, min , max 1100-1300
Fuel-air mixing method Direct injection
Fuel feed equipment Separate type
High-pressure fuel injection pump Six-plunger (in-line or V-type)
Injectors Closed, with multi-jet sprayers
Lubriion system Composed type: pressure-forced and splashing, with oil cooling in oil-liquid heat-exchanger. Besides, oil delivers through the system of channels and pipelines for jet cooling pistons



High Precision YaMZ Direct Drive Fan For Excavator Engine Maz Auto Parts 236HE-1308011-E 0

High Precision YaMZ Direct Drive Fan For Excavator Engine Maz Auto Parts 236HE-1308011-E 1





Packaging & Delivery

Delivery time: 1-3days(if goods in stock only 1 day,if out of stock more than 7days)

Packaging Detail:Standard or as per your requirement

Port:Huangpu,Guangzhou
