Adjustable 82 V DC Automatic Voltage Regulator AVR E000-24403 Live Terminals And Heatsink AS440

China Adjustable 82 V DC Automatic Voltage Regulator AVR E000-24403 Live Terminals And Heatsink AS440 supplier

Large Image :  Adjustable 82 V DC Automatic Voltage Regulator AVR E000-24403 Live Terminals And Heatsink AS440

Product Details:

Place of Origin: China
Brand Name: Generic
Model Number: AS440 E000-24403

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: negotiation
Packaging Details: standard export box
Delivery Time: 1-3days if goods in stock
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000pcs per month
Contact Now
Detailed Product Description
Product Name: Automatic Voltage Regulator Model: AS440
Usage: Generator Avr External Size: 17.5*15*6.5cm
Phase: Single Phase Weight: 0.4kg



AS440 Automatic Voltage Regulator AVR E000-24403 Live Terminals And Heatsink




Specifications:


AS440 Automatic Voltage Regulator AVR E000-24403
1. Type: AVR
2. Condition:New
3. This type is in stock now.




Description:


Sensing Input:

Voltage:Jumper selectable 100-130 Vac 1 phase 190-264 Vac 1 phase

Frequency:50-60 Hz nominal



Power input:

Voltage:100-264 V ac 1 phase

Frequency:50-60 Hz nominal



Output:

Voltage: 82 V d.c. @ 200 V a.c.

Current: Continuous 4A transient 7.5A for 10 secs

Resistance:15 ohms min (10 ohms min when inputVolts is less than 175 ac)

Regulation:± 1.0%

Thermal drift:0.03% per deg. C change in AVR ambient

External voltage adjustment:±-10% with 1kohm 1 watt trimmer Increasing resistance lowers voltage.



Notes:



1. De-rate by 12% if mounted in ‘portrait’ orientation.

2. With 4% engine governing.

3. After 2 minutes.

4. Generator de-rate may apply. Check with factory.

5. Factory set, semi-sealed, jumper selectable.

6. Any device connected to the analogue input must be fully floating (galvanically isolated from ground), with an insulation strength of 500V ac.

7. De-rate output current by 5% per degree C above 60C.

8. Non condensing.



Picture:



Adjustable 82 V DC Automatic Voltage Regulator AVR E000-24403 Live Terminals And Heatsink AS440
