Product Details:
|
| Product Name: | Speed Generator Control Unit | Model: | ESD5550E |
|---|---|---|---|
| Purpose: | Brushless Generator | External Size: | 17.5*15*6.5cm |
| Phase: | Single Phase | Weight: | 0.77kg |
| High Light: | generator automatic voltage regulator avr,electronic voltage regulator for generator |
||
ESD5550E Automatic Voltage Regulator AVR Speed Generator Control Unit
Specifiions:
ESD5550E Automatic Voltage Regulator AVR Speed Generator Control Unit
1. Type: Speed Generator Control Unit
2. Condition:New
3. This type is in stock now.
Description:
The ESD5550/5570 Series speed control unit is an all- electronic device designed to control engine speed with fast and precise response to transient load changes. This closed loop control, when connected to a proportional electric actuator and supplied with a magnetic speed sensor signal, will control a wide variety of engines in an isochronous or droop mode. It is designed for high reliability and built ruggedly to withstand the engine environment. The primary features of the ESD5550/5570 Series speed control unit are the engine STARTING Fuel and SPEED RAMPING adjustments. The use of these features will minimize engine exhaust smoke experienced prior to attaining engine operating speed.
Input:
Supply:12 or 24 VDC Battery System (Transient and Reverse Voltage)
Polarity:Negative Ground (Case Isolated)
Power Consumption:50 ma continuous plus actuator current
Actuator Current Range @ 25 Deg. C - (Inductive Load):Min.2.5 Amps; Max. 10Amps continuous
Speed Sensor Signal:0.5-120 Volts RMS
Environmental:
Ambient Operating Temperature Range:-40 to +80 Deg. C
Relative Humidity:Up to 95%
All Surface Finishes:Fungus Proof and Corrosion Resitant
Reliability:
Vibration:1G,20-100 Hz
Testing:100% Functionally Tested
Our Company Mocun Machinery Parts that strive to provide high quality excavator,bulldozer,loder,truck engine products and hydraulic products.
We supply Genuine & Replacement parts as following:
1. Diesel engine piston, piston pin ,piston rings, piston pin clip, liner etc.
2. Connecting rod, connecting rod bush, connecting rod bearing shells etc
3. Crankshaft, crankshaft oil seal,crankshaft bearing shell, piston cooling nozzle etc
4. Camshaft, camshaft thrust pad, tappet, push rod, camshaft gear etc.
5. Cylinder head, rocker arm, valve sets, valve springs, valve seat, collar,oil seal etc.
6. Turbocharger, Filters, inter-cooler etc.
7. Pumps(fuel transfer pump, lube oil pump, water pump), lube oil cooler core etc.
8. Fuel oil injector, injector nozzle, connector, common rail, high pressure pump etc
9. Starter, electronic parts, governor, air compressor, alternator, fan, belt etc.
10. Gaskets, o-rings, fuel pipes, intake & exhaust pipes, sensors etc
11. Other relevant parts
More Excavator Engine Spare Parts We have:
6BD5.9,6CT8.3,4BT,6BTAA,NH220,NT855,LTA10,KTA19,KTA38,etc
3066,3064,3306,3304,3204,3208,3116,3406,3408,3412,D330A,
D330C,D343,D348,D399,D353,C9,C10,3508,3516,3114,etc
2D92,4D92,4D94,3D95,4D95L,S495,6D95,S6D95,S6D105,6D105,S6D115,S6D102,4D130,4D120,4D105-1,4D105-5,4D106,SD107,S6D108,S6D110,S6D125,S6D140,S6D155,S6D170
S6KT,S4KT,S4F,S4E,S4S,S6A,S6A2,S6B,S6B3,S12R,S6N,S6R,S4KT,K4N,K4M
6D34T,6D31T,4D34T,4D31T,4M4O,4M50 , 6M60, 6D14T,6D15T,6D16T,6D110,6D22,6D24T,6BD1,6DS7,8DC8,8DC9,8DC11,6D20,6D24
3TNV84,3TNE82,4TNV84,4TNE84,4TNE88,3TNV75,3TNV74,3TNV78,4TNE94,4TNE94,4TNV94L,4TNV106, 4TNV98
3KC1,3KR2,4JB1,4JC1,4BD1T,C240,6BD1T,6BG1T,D500,6WQ1,6SD1T,6RB1T,6HK1T,6BB1,6BF1,DA640,DA220,E120,4LE1,4LE2
D1146,D2366,DB58,DO846,DB33
EC140B,EC210B,EC240B,EC290B,EC360B
HINO:
HO6CT,HO7CT,EP100,EM100,EL100,EB100,WO6E,DS50,DS70,EH700,DK10,EF750,F20C,J08C,J05E,J08E,W06D
