190-264V AC Automatic Voltage Regulator AVR 15.2 * 13.5 * 4cm SX440

China 190-264V AC Automatic Voltage Regulator AVR 15.2 * 13.5 * 4cm SX440 supplier
190-264V AC Automatic Voltage Regulator AVR 15.2 * 13.5 * 4cm SX440 supplier 190-264V AC Automatic Voltage Regulator AVR 15.2 * 13.5 * 4cm SX440 supplier

Large Image :  190-264V AC Automatic Voltage Regulator AVR 15.2 * 13.5 * 4cm SX440

Product Details:

Place of Origin: China
Brand Name: Generic
Model Number: SX440

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: negotiation
Packaging Details: standard export box
Delivery Time: 1-3days if goods in stock
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000pcs per month
Contact Now
Detailed Product Description
Product Name: Automatic Voltage Regulator Model: SX440
Weight: 0.45kg Purpose: Brushless Generator
Size: 15.2*13.5*4cm Input Voltage: 190-264V Ac





SX440 Automatic Voltage Regulator AVR For Universal Generator Parts




Specifications:


SX440 Automatic Voltage Regulator AVR For Universal Generator Parts
1. Type: Automatic Voltage Regulator
2. Condition:New
3. This type is in stock now.





Description:



SX440 is a half-wave phase-controlled thyristor type Automatic Voltage Regulator and forms part of the excitation system for a brushless generator. In addition to regulating the generator voltage, the AVR circuitry includes under speed and sensing loss protection to ensure safe, reliable control of the generator

The Propose employs surface mount technology (SMT) for high integration of features in a minute footprint AVR. Positive voltage build up from residual levels is ensured by the use of proficient semiconductors in the power circuitry of the AVR. The control and voltage sensing circuits have separate terminals, allowing the excitation power to be resulting directly from the stator winding for necessary applications or from an auxiliary winding if sustained short circuit performance is essential. Which is linked with the main stator windings and the exciter field windings to offer closed loop control of the output voltage with load regulations of +/- 1%



Technical parameter:



Input voltage:190-264V AC

Frequency:50-60Hz nominal

Phase:1

Wire:2



Output voltage:Max 90V dc at 207V ac input

Current:Continuous 4 A dc/Intermittent 6A for 10 secs

Resistance:15 ohms minimum

Regulation:+/- 1.0% (see note 1)

Thermal drift:0.04% per deg. C change in AVR ambient (note 2)
