Single Phase Automatic Voltage Regulator AVR For Generator Parts SX460

China Single Phase Automatic Voltage Regulator AVR For Generator Parts SX460 supplier

Large Image :  Single Phase Automatic Voltage Regulator AVR For Generator Parts SX460

Product Details:

Place of Origin: China
Brand Name: Generic
Model Number: SX460

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: negotiation
Packaging Details: standard export box
Delivery Time: 1-3days if goods in stock
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000pcs per month
Contact Now
Detailed Product Description
Product Name: Automatic Voltage Regulator Model: SX460
Part Number: PG36658Q2/L Weight: 0.35kg
Size: 15.5*10.5*0.55cm Input Voltage: Max 90V Dc At 207V Ac Input



SX460 Single Phase Automatic Voltage Regulator AVR For Generator Parts




Specifications:


SX460 Single Phase Automatic Voltage Regulator AVR For Generator Parts
1. Type: SX460 Automatic Voltage Regulator
2. Condition:New
3. This type is in stock now.

4. Weight:0.55kg

5. Packing size:155*105*55mm



Description:



AVR SX460 is the standard AVR offered with generators in the lower power bands, achieving voltage regulation in the order of 1.5 %. A feature of this (and all AVR's) is that output voltage is reduced with speed below the normal operating level, to assist the engine or prime mover to recover after sudden application of a heavy load. This is an ideal choice for applications where a generator set is to be run in a stand-alone application where no specialist requirements exist.





Technical parameter:

Voltage:190~260VAC

Frequency:50/60Hz

Current continuous:4A DC



Typical system response:
AVR response 20ms
Filed current to 90% 80 ms
Machine Volts to 97% 300ms


External voltage adjustment:
+/-10% with 1 k ohm 1 watt trimmer (see note 3)
UNDER FREQUENCY PROTECTION
Set point 95% Hz (see note 4)
Slope 170% down to 30 Hz
