Product Details:
|
| Product Name: | Deep Sea Genset Control Panel | Model: | DSE501K |
|---|---|---|---|
| Weight: | 0.39kg | Purpose: | Brushless Generator |
| Size: | 13*7.2*7cm | Input Range: | 15 - 305 V AC RMS |
| High Light: | generator automatic voltage regulator avr,electronic voltage regulator for generator |
||
DSE501K Electronics Generator PLC Deep Sea Genset Control Panel
Specifiions:
DSE501K Electronics Generator PLC Deep Sea Genset Control Panel
1. Type: Automatic Voltage Regulator
2. Condition:New
3. This type is in stock now.
Description:
The Model DSE501K Deep Sea Controller is a Manual Engine Control Module, which has been designed to manually control the engine via a key switch on t front panel. The module is used to start and stop the engine, indiing fault conditions; automatically shutting down the engine and indiing the engine failure by LED giving true first up fault annunciation.
Technical Parameter:
DC Supply----9~33V continuous.
Alternator Input Range----15~305V AC RMS
Alternator Input Frequency---- 50~60Hz at rated engine speed.
Magnetic Input Range----0.5V~+/-80V
Magnetic Input Frequency----2300Hz~6000Hz
Start Relay Output----16 Amp DC at supply voltage
Run Relay Output----16 Amp DC at supply voltage
Alarm Output----1Amp DC at supply voltage
Operating Temperature Range----- -30~70celsius
Operation:
The Deep Sea DSE501K Genset Controller is via a three position key switch mounted on the front panel with STOP(O), RUN(I) and START(II) positions. In the ‘O’ position the DC provide is removed from the module and the run relay and alarm output are de-energised. If the switch is turned to the ‘I’ position the module is powered up and the run relay is energised, activating the engine fuel/ignition system and the protection hold-off timer is initiated. If the switch is moved to the ‘II’ position and held against the spring return, a positive provide is applied to the relevant output terminal and on to the starter motor. Once the engine has started the switch should be released and allowed to return to the ‘I’ position.
Product Picture:
